TechnicalSpecifications:
Test method
1 point end, 2 point end(Sample blank), Kinetics, Fixed-time, Coagulation(optional).
Optics
7 standard filters: 340nm, 405nm, 450nm, 505nm, 546nm, 578nm, 630nm. 2 more for optional.
Lamp house
Long-life tungsten halogen lamp(6V/10W); auto-sleep function.
Display
7.0" TFT LCD with touch screen, 800*480 pixels.
Printer
Build-in thermal printer, 57mm printer paper.
Temperature
25, 30, 37℃ and Room temperature. By means of Peltier elements.
Flow cell capacity & optical path
32μl,10mm.
Resolution
0.0001 Abs.
Photometric range
0.0000-4.0000 Abs.
CPU
ARM Cortex-A8, 720M Hz.
Memory
DDR2 SDRAM: 1G bit;
Flash
256 MB;
Over 300 programs; 200000 results can be stored.
Interface
4 USB Hosts, 1 USB Slave, 1 Ethernet port.
USB port(host) for keyboard, mouse, printer, U disk, barcode reader etc.
USB port(slave) for PC connection(support PC software control function).
Operational environment Temperature
10°C~30°C, Humidity: 30%~80%.
Power requirement
Wide power supply AC 100-240V, 50/60 Hz.
Dimension
400*300*160mm(L*W*H).
